Touchless Automatic Jet Wash

In Stock

The system is provided with robotic undercarriage wash gantry with nine oscillating nozzles on a moving gantry covering every corner of the outer body,underbody,front to back and side washing with foam & wax in up and down cycles. It takes not more than six min. to wash the outer body and achieves good cleaning on dirty vehicles.Complete system is provided with plc control and HMI system for locating the vehicle and also selecting the vehicle length.

Description

Descripition

The system is provided with robotic undercarriage wash gantry with nine oscillating nozzles on a moving gantry covering every corner of the outer body,underbody,front to back and side washing with foam & wax in up and down cycles. It takes not more than six min. to wash the outer body and achieves good cleaning on dirty vehicles.Complete system is provided with plc control and HMI system for locating the vehicle and also selecting the vehicle length.

Features

  • Solid ceramic plungers
  • Stainless stell check valves
  • Heat treated crank shafts
  • High strength bronze or aluminum alloy connectiong rods.
  • Increase work efficiency and maximizes the work output
  • Heavy duty forged brass manifolds.

Technical Specification

High Pressure Triple Ceramic Plunger Pump 40 l/min
Nozzle Pressure 150bar
Power Requirement 11-12 Kw
Power Consumption 1 unit p/vehicle
Water Consumption Per Vehicle 120 to 140 ltr
Time Required For Underbody Wash 6 to 8
Washing LxWxH 5.8×2.2×2.6 mtr
Total No Of Cycle 6 Cycles
Time Required Per Cycle 1.5 min
Chemical Wash Automatic
Automation PLC with HMI Control System
Dryer System NO
Get in touch with us, your one stop point for automatic car wash machine manufacturers in Noida.
